Stainless Steel 310/310S
Stainless steel 310/310S is an austenitic heat resistant alloy with excellent resistance to oxidation under mildly cyclic conditions through 2000ºF. Its high chromium and nickel contents provide comparable corrosion resistance, superior resistance to oxidation and the retention of a larger fraction of room temperature strength than the common austenitic alloys like Type 304. Stainless 310 is often used at cryogenic temperatures, with excellent toughness to -450°F, and low magnetic permeability. **As you can see below, Grade 310S is a low carbon version of grade 310. 310S is less prone to embrittlement and sensitization in service.
In what form is Stainless Steel 310/310S Available at Vessco Overseas.?
310 UNS S31000 Chemical Composition(%)
| Cr | Ni | C | Si | Mn |
|---|---|---|---|---|
| 24.0-26.0 | 19.2-22.0 | .25 Max | 1.50 Max | 2.00 Max |
| P | S | Mo | Cu | Fe |
| .045 Max | .03 Max | .75 Max | .50 Max | Balance |
310S UNS S31008 Chemical Composition(%)
| Cr | Ni | C | Si | Mn |
|---|---|---|---|---|
| 24.0-26.0 | 19.2-22.0 | .08 Max | 1.50 Max | 2.00 Max |
| P | S | Mo | Cu | Fe |
| .045 Max | .03 Max | .75 Max | .50 Max | Balance |
What are the characteristics of 310/310S Stainless Steel?
Oxidation resistance to 2000°F
Moderate strength at high temperature
Resistance to hot corrosion
Strength and toughness at cryogenic temperatures
In what applications is 310/310S Stainless Steel used?
Kilns
Heat Exchangers
Radiant Tubes
Muffles, retorts, annealing covers
Tube hangers for petroleum refiing adn steam boilers
Coal gasifier internal components
Saggers
Furnace parts, conveyor belts, rollers, oven linings, fans
Food processing equipment
Cryogenic structures
Fabrication with Stainless 310/310S
Type 310/310S is readily fabricated by standard commercial procedures. In comparison to carbon steel, stainless steels are tougher and tend to work harden rapidly. Type 310/310S can be welded using all of the common welding processes..
Mechanical Properties
Representative Tensile Properties
| Temperature, °F | Ultimate Tensile Strength, ksi | .2% Yield Strength, ksi | Elongation Percent |
|---|---|---|---|
| 70 | 80.0 | 35.0 | 52 |
| 1000 | 67.8 | 20.8 | 47 |
| 1200 | 54.1 | 20.7 | 43 |
| 1400 | 35.1 | 19.3 | 46 |
| 1600 | 19.1 | 12.2 | 48 |
Typical Creep-Rupture Properties
| Temperature, °F | Minimum Creep 0.0001%/hr, ksi | 100,000 Hour Rupture Strength, ksi |
|---|---|---|
| 12000 | 14.9 | 14.4 |
| 1400 | 3.3 | 4.5 |
| 1600 | 1.1 | 1.5 |
| 1800 | .28 | .66 |
