Duplex S31803
We are stockists of 31803 duplex alloys in sheet, plate, and bar directly distributed globally from our UK stockholding warehouse, combined with our large capacity cutting capabilities we can meet requirements for many industries.
Properties of 31803
Application
Components in the chemical industry, e.g. separator and heat exchanger parts, from the paper industry, oil and gas production, compressor parts, seawater desalination plants.
Technical Info
Chemical Composition(%)
| C | Si | Mn | Cr | Mo | Ni | N |
|---|---|---|---|---|---|---|
| 0.025 | 0.60 | 1.30 | 22.60 | 3.20 | 5.80 | 0.17 |
Standards
| EN / DIN | ASTM | UNS | AFNOR |
|---|---|---|---|
| <1.4462 > X2CrNiMoN22-5-3 |
A240 | S31803 | Z2CND22-5 Az |
Hot Forming
Forging
1200 to 950°C / Air cooling
Heat Treatment
Solution annealing:
1020 to 1100°C
Water , air (thickness below 2mm)
Structure
Ferrite + Austenite
Mechanical Properties
Condition: solution annealed
| Product | Dimension Size mm |
0.2% proof stress N/mm2 min. |
Tensile strength N/mm2 |
Elongation A5 % min. L Q T |
Impact strength (ISO-V) J min. L Q T |
|---|---|---|---|---|---|
| St | ≤ 160 | 450 | 650 – 880 | 25 - – - - | 100 - – - - |
| Bl | ≤ 75 | 460 | 640 – 840 | 252) 252) - - | 90 60 - - |
St = Bar ,
Bl = Sheet or plate
L = Longitudinal, Q = Transverse, T = Tangential
1) For sheet or plate < 3mm = A80mm specimen
The values for other products and dimensions shall be established by
agreement.
High Temperature Properties
Condition: solution annealed
| 0.2% yield strength N/mm² min. |
Temperature | |||
|---|---|---|---|---|
| 100°C | 150°C | 200°C | 250°C | |
| 360 | 335 | 315 | 300 | |
Welding
Good weldability. Welding is possible with all processes usual for stainless steels. We recommend depending on applications electric arc welding with covered electrodes, inert gas welding or SA-welding. Preheating and heat treatment after welding is not necessary. For high stressed heavy walled constructions the limited preheat temperature of 150°C maximum is recommendable. Maximum interpass temperature 150°C. Keep heat input low especially for small wall thicknesses. The TIG-process should be given reference for root welding.
Physical Properties
Thermal conductivity at ……………….. 20°C ………………15.0 ………W/(m.K)
Specific heat at …………………………..20°C ………………500 ……….J/(kg.K)
Electrical resistivity at …………………. 20°C ………………0.80 ………Ohm.mm2/m
Modulus of elasticity at ……………….. 20°C ………………200 x 103 N/mm2
Magnetic properties ……………………………………………..magnetic
| Thermal expansion between 20°C and …°C, 10-6 m/(m.K) at |
Temperature | 10-6 m/(m.K) |
|---|---|---|
| 100°C | 13.0 | |
| 200°C | 13.5 | |
| 300°C | 14.0 |
| Modulus of elasticity, 103 N/mm2 at | Temperature | 103 N/mm2 |
|---|---|---|
| 20°C | 200 | |
| 100°C | 194 | |
| 200°C | 186 | |
| 300°C | 180 |
As regards applications and processing steps that are not expressly mentioned in this product description/data sheet, the customer shall in each individual case be required to consult us.
