Nimonic Alloys 80A
Alloy 80A is a nickel-chromium alloy similar to alloy 75 but made precipitation hardenable by additions of aluminium and titanium. Alloy 80A has good corrosion and oxidation resistance and high tensile and creep-rupture properties at temperatures to 815ºC (1500ºF). Alloy 80a is used for gas-turbine components (blades, rings, discs), bolts, tube supports in nuclear generators, exhaust valves in internal combustion engines and has many other offshore/marine, automotive and electrical applications.
In what form is Nimonic 80A Available at Vessco Overseas.?
Chemical Composition (%)
| Weight % | Ni | Cr | Ti | Al | C | Si | Cu | Fe | Mn | Co | B | Zr | S |
| Alloy 80A | Bal |
18.0-21.0 |
1.8-2.7 |
1.0-1.8 | 0.10 max | 1.0 max | 0.2 max | 3.0 max | 1.0 max | 2.0 max | 0.008 max | 0.15 max | 0.015 max |
Mechanical Properties
| Rupture Strength (1000 h) | ||
|---|---|---|
| Temperature | psi | MPa |
| 760°C / 1400° F | 6000 | 40 |
| 815°C / 1500°F | 3500 | 24 |
| 870°C / 1600°F | 2200 | 15 |
| 925°C / 1700°F | 1500 | 10 |
| 980°C / 1800°F | 1200 | 8 |
Specifications
| Rupture Strength (1000 h) | ||
|---|---|---|
| Temperature | ksi | MPa |
| 595°C / 1100°F | 94 | 650 |
| 650°C / 1200°F | 73 | 500 |
| 705°C / 1300°F | 51 | 350 |
| 760°C / 1400°F | 32 | 220 |
| 815°C / 1500°F | 16 | 110 |
