A martinsitic precipitation hardening steel, Custom 450 mstainless steel offers high strength combined with excellent corrosion resistance similar to 304 stainless in corrosion resistance with moderate strength similar to that of 410 stainless. As with most precipitation hardened alloys, Custom 450 stainless has excellent transverse properties.
Used when ease of welding and brazing in fabrication is required. Custom 450, unlike many precipitation hardening grades, Custom 450 can be used in the annealed condition.
The following table is for reference only, many factors can affect the corrosive resistance, a corrosion test for each application should be applied.
Phosphoric acid | Restricted | Acetic Acid | Moderate |
Sodium Hydroxide | Moderate | Sea Water | Restricted |
Salt Spray | Good | Nitric Acid | Good |
Sulfuric Acid | Restricted | Humidity | Excellent |
Sour oil/gas | Moderate |
Carbon | max | 0.05% | Manganese | max | 1.00% |
Phosphorus | max | 0.03% | Sulfur | max | 0.030% |
Silicon | max | 1.0% | Chromium | 14.00 - 16.00% | |
Nickel | 5.00-7.00% | Columbium + Niobium | 8 X C Minimum | ||
Iron | Balance | Molybdenum | 0.50-1.00% |
Solution treated 1875/1925f (1024/1052c) and air cooled, followed by tempering at indicated temperature
Temper Temperature | Yield 0.2% | Yield 0.2% | Ultimate Tensile Strength | % Elongation in 2" {50.8mm} | hardness Brinell c |
% Reduction of Area | Charpy V-notch | ||
---|---|---|---|---|---|---|---|---|---|
0.2% offset | 0.2% offset | ft-lb | J | ||||||
F | ksi | mpa | ksi | Mpa | |||||
Annealed | 118 | 814 | 142 | 978 | 13 | 28 | 50 | 98 | 133 |
H900 | 188 | 1296 | 196 | 1351 | 14 | 42 | 56 | 40 | 54 |
H950 | 184 | 1269 | 187 | 1289 | 16 | 41 | 58 | 47 | 64 |
H1000 | 169 | 1165 | 173 | 1193 | 17 | 39 | 63 | 51 | 69 |
H1050 | 152 | 1048 | 160 | 1103 | 20 | 37 | 66 | 69 | 94 |
H1150 | 92 | 634 | 142 | 979 | 23 | 28 | 69 | 97 | 132 |
